[Material Description]

         Polyether Ether Ketone(PEEK),is an organic polymer thermoplastic. It is a semicrystalline thermoplastic with excellent mechanical and chemical resistance properties that are retained to high temperatures. PEEK has a glass transition temperature at around 143 °C and melts around 343 °C.

[Properties]

                 Excellent high temperature resistance,  can work long duration in the temperature of 250°C, which is 50°C higher than PI, PPS, PTFE or PPO.

                 Excellent mechanical properties, high strength even in high temperature, high modulus, high fracture toughness, excellent dimensional stability and high repeat autoclavability. PEEK has the

similar properties as aluminum for its high rigidness, dimensional stability and small linear expansion coefficient.

                 Excellent chemical resistance only dissolves in concentrated sulfuric acid. PEEK has the same corrosion resistance as nickel steel, and it has low flammability value.

                 Excellent wear resistance, especially under 250°C, it maintains high wear resistance and low friction coefficient.

                 Excellent insulation stability, hydrolysis resistance

                 Excellent biocompatibility

[Applications]

                 Protective/supportive tubing for medical devices, insulation tube, wear-resisting tube

[Sizes]

                 Inner diameter: 1.00mm-10.00mm

                 Wall thickness: 0.20mm-3.00mm

[Grade]

                 USP Class VI, Food & Beverage Grade, Industrial grade

[Production Environment]

               Standard Class 100,000 Cleanroom
